How to configure trunk on Cisco Catalyst Switch

Trunks are required to carry VLAN traffic from one switch to another. In this article I will demonstrate how to configure a trunk between Cisco Catalyst switches. Let me show you the topology that we’ll use:

Two Cisco switches

Above you see a topology with a computer connected to each switch. We’ll put the computers in the same VLAN and create a trunk between the two switches. Let’s start by creating a VLAN:

SwitchA(config)#vlan 50
SwitchA(config-vlan)#name Computers
SwitchA(config-vlan)#exit
SwitchB(config)#vlan 50
SwitchB(config-vlan)#name Computers
SwitchB(config-vlan)#exit

And let’s put the interfaces connected to the computers in the correct VLAN:

SwitchA(config)#interface fa0/1
SwitchA(config-if)#switchport access vlan 50
SwitchB(config)#interface fa0/2
SwitchB(config-if)#switchport access vlan 50

The next step is to create a trunk between the two switches. Technically the interfaces between the two switches can also be in access mode right now because I only have a single VLAN.

SwitchA(config)#interface fa0/14
SwitchA(config-if)#switchport mode trunk
Command rejected: An interface whose trunk encapsulation is "Auto" can not be configured to "trunk" mode.
SwitchB(config)#interface fa0/14
SwitchB(config-if)#switchport mode trunk
Command rejected: An interface whose trunk encapsulation is "Auto" can not be configured to "trunk" mode.

I try to change the interface to trunk mode with the switchport mode trunk command. Depending on the switch model you might see the same error as me. If we want to change the interface to trunk mode we need to change the trunk encapsulation type. Let’s see what options we have:

SwitchA(config-if)#switchport trunk encapsulation ?
  dot1q      Interface uses only 802.1q trunking encapsulation when trunking
  isl        Interface uses only ISL trunking encapsulation when trunking
  negotiate  Device will negotiate trunking encapsulation with peer on interface

This is where you can choose between 802.1Q or ISL encapsulation. By default our switch will negotiate about the trunk encapsulation type.

SwitchA(config-if)#switchport trunk encapsulation dot1q
SwitchB(config-if)#switchport trunk encapsulation dot1q

Let‟s change it to 802.1Q by using the switchport trunk encapsulation command.

SwitchA#show interfaces fa0/14 switchport
Name: Fa0/14
Switchport: Enabled
Administrative Mode: dynamic auto
Operational Mode: static access
Administrative Trunking Encapsulation: dot1q
SwitchB#show interfaces fa0/14 switchport
Name: Fa0/14
Switchport: Enabled
Administrative Mode: dynamic auto
Operational Mode: static access
Administrative Trunking Encapsulation: dot1q

As you can see the trunk encapsulation is now 802.1Q.

SwitchA(config)#interface fa0/14
SwitchA(config-if)#switchport mode trunk
SwitchB(config)#interface fa0/14
SwitchB(config-if)#switchport mode trunk

Now I can successfully change the switchport mode to trunk.

SwitchA#show interfaces fa0/14 switchport
Name: Fa0/14
Switchport: Enabled Administrative Mode: trunk Operational Mode: trunk
Administrative Trunking Encapsulation: dot1q
Operational Trunking Encapsulation: dot1q
SwitchB#show interfaces fa0/14 switchport
Name: Fa0/14
Switchport: Enabled Administrative Mode: trunk Operational Mode: trunk
Administrative Trunking Encapsulation: dot1q
Operational Trunking Encapsulation: dot1q

We can confirm we have a trunk because the operational mode is “dot1q”.

Let‟s try if ComputerA and ComputerB can reach each other:

C:\Documents and Settings\ComputerA>ping 192.168.1.2

Pinging 192.168.1.2 with 32 bytes of data:

Reply from 192.168.1.2: bytes=32 time<1ms TTL=128
Reply from 192.168.1.2: bytes=32 time<1ms TTL=128
Reply from 192.168.1.2: bytes=32 time<1ms TTL=128
Reply from 192.168.1.2: bytes=32 time<1ms TTL=128

Ping statistics for 192.168.1.2:
Packets: Sent = 4, Received = 4, Lost = 0 (0% loss),
Approximate round trip times in milli-seconds:
Minimum = 0ms, Maximum = 0ms, Average = 0ms

Excellent! ComputerA and ComputerB can reach each other! Does this mean we are
done? Not quite yet…there‟s more I want to show to you:

SwitchB#show vlan
VLAN Name                             Status    Ports
---- -------------------------------- --------- -------------------------------
1    default                          active    Fa0/1, Fa0/3, Fa0/4, Fa0/5
                                                Fa0/6, Fa0/7, Fa0/8, Fa0/9
                                                Fa0/10, Fa0/11, Fa0/12, Fa0/13
                                                Fa0/15, Fa0/22, Fa0/23, Fa0/24
                                                Gi0/1, Gi0/2
50   Computers                        active    Fa0/2

First of all, if we use the show vlan command we don’t see the Fa0/14 interface. This is completely normal because the show vlan command only shows interfaces in access mode and no trunk interfaces.

SwitchB#show interface fa0/14 trunk
Port        Mode             Encapsulation  Status        Native vlan
Fa0/14      on               802.1q         trunking      1
Port        Vlans allowed on trunk
Fa0/14      1-4094
Port        Vlans allowed and active in management domain
Fa0/14      1,50
Port        Vlans in spanning tree forwarding state and not pruned
Fa0/14      50

The show interface trunk command is very useful. You can see if an interface is in trunk mode, which trunk encapsulation protocol it is using (802.1Q or ISL) and what the native VLAN is. We can also see that VLAN 1 – 4094 are allowed on this trunk.

We can also see that currently only VLAN 1 (native VLAN) and VLAN 50 are active. Last but not least you can see something which VLANs are in the forwarding state for spanning-tree.

Before we continue with the configuration of VTP I want to show you one more thing about access and trunk interfaces:

SwitchB#show interface fa0/2 switchport
Name: Fa0/2
Switchport: Enabled
Administrative Mode: static access
Operational Mode: static access

An interface can be in access mode or in trunk mode. The interface above is connected to ComputerB and you can see that the operational mode is “static access” which means it’s in access mode.

SwitchB#show interfaces fa0/14 switchport
Name: Fa0/14
Switchport: Enabled
Administrative Mode: trunk
Operational Mode: trunk

This is our trunk interface which is connected to SwitchA. You can see the operational mode is trunk mode.

SwitchB(config-if)#switchport mode ?
  access        Set trunking mode to ACCESS unconditionally
  dot1q-tunnel  set trunking mode to TUNNEL unconditionally
  dynamic       Set trunking mode to dynamically negotiate access or trunk
  private-vlan  Set private-vlan mode
  trunk         Set trunking mode to TRUNK unconditionally

If I go to the interface configuration to change the switchport mode you can see I have more options than access or trunk mode. There is also a dynamic method. Don’t worry about the other options for now.

SwitchB(config-if)#switchport mode dynamic ?
  auto       Set trunking mode dynamic negotiation parameter to AUTO
  desirable  Set trunking mode dynamic negotiation parameter to DESIRABLE

We can choose between dynamic auto and dynamic desirable. Our switch will automatically find out if the interface should become an access or trunk port. So what’s the difference between dynamic auto and dynamic desirable? Let’s find out!

SwitchA and SwitchB

I’m going to play with the switchport mode on SwitchA and SwitchB and we’ll see what the result will be.

SwitchA(config)#interface fa0/14
SwitchA(config-if)#switchport mode dynamic auto
SwitchA(config)#interface fa0/14
SwitchB(config-if)#switchport mode dynamic auto

First I’ll change both interfaces to dynamic auto.

SwitchA(config-if)#do show interface f0/14 switchport
Name: Fa0/14
Switchport: Enabled
Administrative Mode: dynamic auto
Operational Mode: static access
SwitchB(config-if)#do show interface f0/14 switchport
Name: Fa0/14
Switchport: Enabled
Administrative Mode: dynamic auto
Operational Mode: static access

Our administrative mode is dynamic auto and as a result we now have an access port.

SwitchA(config)#interface fa0/14
SwitchA(config-if)#switchport mode dynamic desirable
SwitchB(config)#interface fa0/14
SwitchB(config-if)#switchport mode dynamic desirable
SwitchA#show interfaces fa0/14 switchport
Name: Fa0/14
Switchport: Enabled
Administrative Mode: dynamic desirable
Operational Mode: trunk
SwitchB#show interfaces fa0/14 switchport
Name: Fa0/14
Switchport: Enabled
Administrative Mode: dynamic desirable
Operational Mode: trunk

Once we change both interfaces to dynamic desirable we end up with a trunk link. What do you think will happen if we mix the switchport types? Maybe dynamic auto on one side and dynamic desirable on the other side? Let’s find out!

SwitchA(config)#interface fa0/14
SwitchA(config-if)#switchport mode dynamic desirable
SwitchB(config)#interface fa0/14
SwitchB(config-if)#switchport mode dynamic auto
SwitchA#show interfaces f0/14 switchport
Name: Fa0/14
Switchport: Enabled
Administrative Mode: dynamic desirable
Operational Mode: trunk
SwitchB#show interfaces fa0/14 switchport
Name: Fa0/14
Switchport: Enabled
Administrative Mode: dynamic auto
Operational Mode: trunk

It seems our switch has a strong desire to become a trunk. Let’s see what happens with other combinations!

SwitchA(config)#interface fa0/14
SwitchA(config-if)#switchport mode dynamic auto
SwitchB(config)#interface fa0/14
SwitchB(config-if)#switchport mode trunk
SwitchA#show interfaces f0/14 switchport
Name: Fa0/14
Switchport: Enabled
Administrative Mode: dynamic auto
Operational Mode: trunk
SwitchB#show interfaces fa0/14 switchport
Name: Fa0/14
Switchport: Enabled
Administrative Mode: trunk
Operational Mode: trunk

Dynamic auto will prefer to become an access port but if the other interface has been configured as trunk we will end up with a trunk.

SwitchA(config)#interface fa0/14
SwitchA(config-if)#switchport mode dynamic auto
SwitchB(config)#interface fa0/14
SwitchB(config-if)#switchport mode access
SwitchA#show interfaces f0/14 switchport
Name: Fa0/14
Switchport: Enabled
Administrative Mode: dynamic auto
Operational Mode: static access
SwitchB#show interfaces fa0/14 switchport
Name: Fa0/14
Switchport: Enabled
Administrative Mode: static access
Operational Mode: static access

Configuring one side as dynamic auto and the other one as access and the result will be an access port.

SwitchA(config)#interface fa0/14
SwitchA(config-if)#switchport mode dynamic desirable
SwitchB(config)#interface fa0/14
SwitchB(config-if)#switchport mode trunk
SwitchA#show interfaces f0/14 switchport
Name: Fa0/14
Switchport: Enabled
Administrative Mode: dynamic desirable
Operational Mode: trunk
SwitchB#show interfaces fa0/14 switchport
Name: Fa0/14
Switchport: Enabled
Administrative Mode: trunk
Operational Mode: trunk

Dynamic desirable and trunk mode offers us a working trunk.

What do you think will happen if I set one interface in access mode and the other one as trunk? Doesn’t sound like a good idea but let’s push our luck:

SwitchA(config)#interface fa0/14
SwitchA(config-if)#switchport mode access
SwitchB(config)#interface fa0/14
SwitchB(config-if)#switchport mode trunk
SwitchA#show interfaces f0/14 switchport
Name: Fa0/14
Switchport: Enabled
Administrative Mode: static access
Operational Mode: trunk
SwitchB#show interfaces fa0/14 switchport
Name: Fa0/14
Switchport: Enabled
Administrative Mode: trunk
Operational Mode: trunk
SwitchA#
%SPANTREE-7-RECV_1Q_NON_TRUNK: Received 802.1Q BPDU on non trunk FastEthernet0/14 VLAN1.
%SPANTREE-7-BLOCK_PORT_TYPE: Blocking FastEthernet0/14 on VLAN0001. Inconsistent port type.
%SPANTREE-2-UNBLOCK_CONSIST_PORT: Unblocking FastEthernet0/14 on VLAN0001. Port consistency restored.

As soon as I change the switchport mode I see these spanning-tree error messages on SwitchA. Spanning-tree is a protocol that runs on switches that prevents loops in our network.

Let me give you an overview of the different switchport modes and the result:

  Trunk Access Dynamic Auto Dynamic Desirable
Trunk Trunk Limited Trunk Trunk
Access Limited Access Access Access
Dynamic Auto Trunk Access Access Trunk
Dynamic Desirable Trunk Access Trunk Trunk

That’s all I have for you now about trunking. I hope this was useful to you. It’s best if you try some of these commands on your own switches so that you become familiar with the different commands. If you enjoyed this article, please leave a comment or share it with your friends!
